A tenant panel is one rectangle in a shared sign, so replacing it can sound like a simple swap. It rarely is.
The new panel has to fit a cabinet that is already standing. It may sit beside older faces, share their lighting, and be subject to a lease or property standard. The property, tenant, and sign provider also need to agree on dimensions, artwork, cost, access, and approval. Most delays begin in one of those handoffs, not during fabrication.
Inventory the sign before ordering
A provider cannot tell what is standing at the property from a lease or logo file. Document the existing sign before a tenant change turns the work into a rushed order.
Record every panel position
Work from the top of the sign to the bottom and give every slot a number. Include empty positions, blank panels, and temporary faces. For each one, record:
- the tenant currently displayed
- overall panel dimensions
- the visible opening inside the retainer or frame
- the face and side of the sign where it appears
- whether the same artwork appears on the opposite face
- the panel's visible condition
Photograph fading, crazing, water stains, bowed material, or a panel that no longer sits flat. A new panel may look noticeably different beside an older one, even when its own specifications are correct.
Use the position numbers in artwork files, quotes, proofs, and emails. Directions such as "the third panel down on the left" become unreliable once several people are involved.
Describe the sign and its surroundings
Record whether the sign is a pole-mounted pylon or a ground-level monument, and whether it has one face or two. Note any fixed header or property-identification panel above the tenant positions. Estimate how high the lowest and highest positions sit above grade without climbing or reaching.
The area around the sign matters too. Photograph landscaping, curbs, drive aisles, parked vehicles, slopes, and other conditions that may affect access.
If the cabinet appears to be internally illuminated, note whether all positions light the same way and whether any position is dark. A dark face is something a qualified party should evaluate. Do not diagnose the cause from the parking lot.
Find the existing records
Look for the original sign drawings, the sign criteria attached to tenant leases, earlier permit paperwork, previous vendor invoices, and recorded property restrictions. These records can answer questions that photographs cannot.
Older properties often have incomplete files. If records are missing, say so in the quote request. Use current photographs and measured dimensions as the working record rather than treating an old assumption as a specification.
Photograph what should not be reached
Take a straight-on photograph of each sign face from a consistent distance. Add a wider view of the sign and its setting, plus close views of a retainer edge and panel corner from the ground. For illuminated signs, take both daytime and nighttime photographs. Uneven lighting between positions may not appear during the day.
Do not measure at height, remove a retainer, or open an illuminated cabinet. Anything that requires climbing, reaching, or access to an energized sign belongs with a qualified party.
Confirm the panel specifications
Most reorder problems begin with a detail that someone assumed. Dimensions, construction, graphics, color, and illumination should all appear in the quote or approved drawing.
Dimensions
A panel has two important sizes. The overall size controls whether it fits the cabinet. The visible opening is the area left after the retainer or frame covers the edges. Artwork built to the overall size can lose copy or logo details at the border.
Confirm both measurements, the panel thickness, corner treatment, and how the panel is held in place. Record whether it slides into a track or sits behind a removable retainer. Note any required holes or notches.
Older signs do not always match their original drawings. Before ordering, settle who verifies the fit, whether the scope includes a template or field measurement, and who carries the cost if the finished panel does not seat correctly.
Materials and construction
A flat sheet face, a pan-formed or embossed face, and an aluminum panel for an unlit position are different products. Translucent acrylic and polycarbonate are also different materials chosen for different project needs.
Each quote should name the material and construction it assumes. Otherwise, a lower total may reflect a different panel rather than a better price for the same work.
Graphics method
Tenant copy and logos may use digitally printed graphics, applied translucent vinyl, routed and backed elements, or more than one method. The choice affects daytime and nighttime appearance, the way color references are handled, and what a later artwork change may require. Ask each provider to state the method included in the quote.
Finish and color
A color approved on a monitor or office printer is not a reliable production reference. Give each element a named color reference. Also confirm matte or gloss finish and whether printing will be on the first or second surface.
An internally illuminated face can look different after dark because daylight reflects from the front while cabinet light passes through the material. If the tenant cares about nighttime appearance, address that during specification and proof review.
Illumination consistency
For an illuminated cabinet, ask how the new panel is expected to look beside the existing faces. A difference may come from the panel, from components behind it, or from the age and condition of neighboring faces.
Do not bury that uncertainty in a panel order. The quote should state whether anything behind the face is included. Lighting or electrical evaluation belongs to the provider's stated scope and, where electrical work is involved, a licensed electrician.
Set property standards and control artwork approval
A written panel standard prevents every incoming tenant from restarting the same negotiation. It also gives the property manager a consistent basis for reviewing artwork.
What the standard should cover
- Exact panel size and visible area for each type of position.
- Required background treatment and whether a tenant may request a different one.
- Permitted copy colors and the process for requesting another brand color.
- Maximum logo area and required clear space.
- Whether taglines, phone numbers, web addresses, or full-bleed images are allowed.
- The illumination style supported by the position.
- How positions are assigned and whether the layout may change for a larger tenant.
- Who pays for the first panel, later artwork changes, and removal when the lease ends.
- What the property displays in a vacant position.
Attach the standard to the lease or sign criteria exhibit. Give it to prospective tenants before they approve a logo layout with their own designer.
Submit and approve artwork in a defined path
Request vector artwork with fonts converted to outlines and a named color reference for each element. A logo copied from a website is usually a low-resolution raster file. If it must be redrawn, the quote and schedule should show that extra design step.
Write down who reviews the layout against the property standard and who at the tenant confirms the legal business name and displayed details. The approval path should also state how many proof rounds are included and what the final approval authorizes. Use a named signer instead of relying on an informal email chain.
Common approval delays
- The tenant supplies a raster image, but nobody allows time or budget for redrawing it.
- The brand guide requires a color outside the property standard, and no one has authority to approve an exception.
- The property approves the layout without confirming the panel size against the cabinet.
- The lease does not say who pays, so the order waits for that decision.
- Several positions change at once, but the shared layout is not rebalanced before proofs begin.
Check how the update affects the existing cabinet
A like-for-like panel replacement is the narrowest version of this work. Adding a position, joining two positions, changing an opening, or rebuilding the full face layout can affect the cabinet itself.
Separate panel replacement from layout changes
State which positions are changing and whether their existing size and arrangement will remain. If the request changes the retainer system, neighboring positions, cabinet section, or total face layout, it is no longer just a panel reorder. Settle that scope before design work begins.
Account for an older cabinet
The existing retainer or extrusion profile may no longer be available in the same form. Earlier repairs, corrosion, a bowed frame, or a nonstandard fix can also affect fit. Even a panel made to the original drawing may not match the opening that exists today.
Someone must evaluate whether the cabinet can accept the proposed panel. The quote should name that responsibility rather than carry fit as an unverified assumption.
Separate structure, lighting, and local review
A change to the sign's dimensions, overall face area, or cabinet sections may be treated differently from a like-for-like panel swap. The municipality, recorded property restrictions, or shopping-center criteria may impose separate requirements. Raise those questions before the layout is developed too far.
If components behind the face need attention, give that work its own scope and owner. Requirements vary by property, municipality, and project. Confirm the final requirements for the address before production or installation.
Plan for access and tenant turnover
A panel that is easy to fabricate may still be difficult to replace. Properties with regular tenant changes have to deal with that difference repeatedly.
Ask how the panel is changed
Confirm how each position is reached, whether one panel can be removed without disturbing its neighbors, and whether replacement retainer hardware is still available. Ask what equipment is needed to reach the position. The same panel at eye level in a monument sign and high on a pylon creates a different service scope.
Keep a panel register
Maintain one record for the whole sign. For each position, list its dimensions, material, graphics method, color references, artwork file location, order date, and vendor. When a tenant leaves, that record allows the next request to begin with known specifications instead of another round of measuring.
Choose the vacancy default now
Decide what appears when a position is empty: a blank panel in the property color, property identification, or the previous tenant's face left temporarily in place. A spare blank in the standard property color can avoid a later dispute and an urgent one-off order.
Assign each part of the update
Several parties may touch one tenant-panel order. The exact division depends on the property, lease, and provider scope. Put each handoff in writing.
| Item | Question to settle in writing | Parties that may be involved |
|---|---|---|
| Panel inventory and measurements | Who records every position, and who verifies dimensions against the cabinet? | Property, sign provider |
| Property sign standard | Who writes it, enforces it, and decides exceptions? | Property owner, property manager |
| Tenant artwork files | Who supplies vector files and color references, and by what date? | Tenant, tenant's designer |
| Artwork redraw | Who redraws an unusable file, and who pays? | Sign provider, designer |
| Layout and proof approval | Who reviews the standard, confirms displayed details, and signs the approval? | Property, tenant, sign provider |
| Fit verification | Who confirms the panel will fit, and who carries a refit? | Sign provider, fabricator, property |
| Fabrication scope | What will be produced, and what is excluded? | Sign provider, fabricator |
| Shipping and receiving | Who receives, inspects, and stores the panels? | Carrier, property, installer |
| Site access and scheduling | Who arranges access, parking, and permission to work? | Property, installer |
| Access equipment | Who provides and pays for the lift or other required equipment? | Installer, property |
| Electrical and lighting review | Who is qualified to evaluate work behind the face, and whose scope includes it? | Licensed electrician, sign provider |
| Removal and installation | Who removes the old panel, installs the new one, and disposes of the old material? | Installer, property |
| Local or property review | Who checks whether review is required, and who submits the materials? | Property, municipality, sign provider |
| Cost allocation | Who pays first, and how is the tenant billed if the lease allows it? | Property, tenant |
| Future changes and spares | How will later panels be requested and priced, and will spares be stocked? | Property, sign provider |
This table does not assign work to Signage.com or any other provider. It identifies decisions the property, tenant, designer, sign provider, fabricator, carrier, electrician, installer, and municipality may need to make for the project.
Compare tenant-panel quotes on the same scope
Two quotes labeled "tenant panels" may include different work. Compare the details before comparing the totals.
| Quote item | What to confirm | Why it changes the comparison |
|---|---|---|
| Panel count and sizes | Positions included, overall dimensions, and visible openings | Pricing the opening instead of the full panel describes a different item |
| Face construction | Flat, formed, or metal face and specified material | Construction can change fabrication work even when the panel count matches |
| Graphics method | Print, applied vinyl, routed and backed, or a combination | The method affects appearance and later artwork changes |
| Color reference | Named references for each element | Screen approval alone can lead to a color dispute |
| Illumination expectation | Whether each panel is lit and how it should sit beside existing faces | This separates the panel from work inside the cabinet |
| Fit responsibility | Template, field measurement, or buyer-supplied dimensions | This determines who carries a refit if the opening differs |
| Artwork and proofs | Included rounds, redraw work, and revision charges | Late artwork changes may fall outside the quoted scope |
| Packing and freight | Crating, delivery, and inspection on arrival | Transit damage needs a named owner and response path |
| Installation | Included, excluded, or arranged separately | Two totals are not comparable when only one includes installation |
| Access equipment | Included, excluded, or billed separately | Height and site access can add work beyond the panel itself |
| Removal and disposal | Old panel removal and disposal | Lower quotes may leave this work out |
| Spares and future panels | Blank or spare faces priced with the current run | A later one-off order is a separate scope |
| Assumptions and taxes | Existing conditions and other assumptions behind the total | An unverified assumption can turn a fixed total into a variable one |
Read every assumption. A low quote may depend on an existing condition that nobody has checked.
Gather the quote inputs
You can begin without every item, but each confirmed detail removes an assumption from the estimate.
- Property address and photographs of each sign face, including day and night views when illuminated.
- A numbered panel schedule covering occupied, vacant, blank, and temporary positions.
- Overall panel dimensions and visible opening dimensions, with a note explaining how they were obtained.
- Sign type, number of faces, and approximate height of the affected position.
- Vector artwork and named color references for each tenant being added or changed.
- The property sign standard, or a note that one does not exist.
- Lease language, recorded restrictions, or shopping-center criteria that affect panel content.
- Known details about cabinet illumination and any currently dark position.
- Site access notes covering drive access, landscaping, slopes, parking, and other restrictions.
- The number of positions needed now and the number the layout may need later.
- A target timeframe treated as a planning input, not a committed completion date.
Reviewing pylon sign options can help you identify the cabinet style, panel arrangement, and illumination approach in front of you. It cannot determine fit, electrical scope, local review, or installation requirements for the property.
Verify the proof before production
Check these points before approving tenant artwork or production:
- Compare the legal business name, trading name, spelling, phone number, suite or unit number, and other displayed details with a source the tenant confirms.
- Match the drawing dimensions to the quote and distinguish the overall panel size from the visible opening.
- Keep copy and logo elements inside the visible area with the required clear space.
- Compare every color with the agreed reference, not only its on-screen appearance.
- Confirm the illumination expectation in writing when the position is lit.
- Determine whether the approval covers a visual concept or production artwork. A visual mockup is a planning aid. It is not engineering, permitting, fabrication, installation, compliance, or production documentation.
- Ask how later changes to tenant details, dimensions, or site findings would affect scope and price.
- Reconfirm the tenant's assigned position if the shared layout changed during the project.
Next step
Once the panel schedule, photographs, dimensions, and tenant artwork are together, request a custom sign quote and attach those materials. They give the provider a clearer description of the sign that exists and give you a better basis for comparing the responses.
